Advantages:
1.Mouth and bottom trimming 2 process finished in 1 machine.
2.High production capacity.
3.Burr-free cutting.
4.No maintenance.
5.Dust collector.
6.No trimming machine requirements.
7.Servo control, PLC control
8.The manipulator is integrated with the equipment, without additional installation and debugging of the manipulator.

Main Technical Parameters
|
Model |
JSB-LG1030BA |
|
Function |
Bottom & top trimming and deburring |
|
Technology |
Laser cutting, Servo control, PLC control |
|
Working pipe diameter |
30-180mm |
|
Working height |
50-400mm |
|
Working thickness |
0.25-0.8mm |
|
Working diatance |
400mm |
|
Output |
4000-6000pcs/8h |
|
Voltage |
AC 380V/AC 415V |
|
Power |
13.5kw(laser source power: 1.5 kw include) |
|
Size |
1382*1319*2650mm |
|
Weight |
1800kg |
