Advantages:
1. To protect user by make the single wall bottle edge round.
2. Pre-welding, make outer wall closer inner wall.
3. Accuracy: Tolerance ±0.1mm.
4. High capacity.

Main Technical Parameters
|
Model |
JSB-CB100 |
|
Function |
Roll the edges of the lid inward into the inside of the lid |
|
Technology |
Servo control |
|
Working diameter |
30-180mm |
|
Working height |
0-110mm |
|
Working thickness |
0.25-0.8mm |
|
Air pressure |
0.6Mpa |
|
Output |
3000-4000pcs/8h |
|
Voltage |
AC 380V/AC 415V |
|
Power |
3kw |
|
Size |
850*1200*2200mm |
|
Weight |
380kg |
