Application
It is an indoor industrial robot, which can realize the automation of factory material transportation.It improves the speed of internal logistics , the safety of employees,and improve the productivity.
Advantages
◎ High speed, high repetition positioning accuracy, and maximize production efficiency
◎ Maximum payload of 5kg, Motion range of 808mm ,which achieve high precision and maximum arm length

Main Technical Parameter
| Structure style | Verticalmulti-joint robot | |
| Degree of freedom | 6 axis | |
| Payload | 5 KG | |
| Max radius of activity | 808 mm | |
| Repeated positioning accuracy | ±0.05mm | |
| Activity range | S axis | ±150° |
| L axis | ±145° | |
| U axis | -90° +165° | |
| R axis | ±135° | |
| B axis | ±145° | |
| T axis | ±360° | |
| Body weight | 24KG | |
| Environmental conditions | Temperature | 0~45° |
| Humidity | 20- 80%RH(No condensation) | |
| Vibration | Below 4.9m/S2 | |
| No flammable and corrosive gas or liquid Do not involve water, oil, powder Do not approach the source of electromagnetic gas |
||
| Battery capacity | 1.60KVA | |
