Advantages:
1.High production capacity.
2.Burr free cutting.
3.No maintenance.
4.Dust collector.
5.No trimming machine required.
6.Zero error length cutting on cup separation.

Main Technical Parameters
|
Model |
JSB-LC1030 |
|
Function |
Deep draw bottom & cap cutting |
|
Technology |
laser cutting, servo system, PLC control |
|
Working pipe diameter |
40-180mm |
|
Working height |
0-110mm |
|
Working thickness |
0.25-0.8mm |
|
Output |
4000-6000pcs/8h |
|
Voltage |
AC 380V/AC 415V |
|
Power |
7.9kw ( Laser cource prower: 1.5 kw include) |
|
Size |
1050*1360*2025 mm |
|
Weight |
1100 kg |
