Product Usage
Widely used in automobile manufacturing, new energy industry, home appliance manufacturing, door and window industry, hardware welding.
Advantage
This machine processing precision, fast speed, stability and practical, high degree of automation, saving labor costs.
Wide welding firm:
Maintenance free operation, non-contact processing, high processing efficiency, the use of robot control, easy to realize automation 7 good stsbility, not easy to deformation.
| Model | JS-SC JAH 1000-3000 |
| Output Power | 1000W / 1500W /2000W /3000W |
| Laser wavelength | 1064nm |
| Output mode | Continuous / Modulated |
| The transmission system | ABB、YASKAWA、KUKA、FANUC |
| Laser type | Spurs / Chuaxin / Raycus |
| Penetration depth | SUS 304 (0.5-5MM) |
| Type of welding joint | Double motor swing welding joint |
| Repeat positioning accuracy | ± 0.03mm |
| Best operating environment | Temperature : 5℃-45℃, humidity: 10%-80% |
| Demand for electricity | 220 VAC 50HZ 30A or 380 VAC 50HZ 40A |
| Cooling way | Water cooled |
| Cold water tank brand | Blue penguin, Quan Guan, Han Li |
| The engineer power | <8kw |
| Focus on the focal length | 200 |
| Control system | Yihong / Kirin |
| Working radius | 914MM |
| The rated load | 30KG |
