Application
Jackson industrial robot is widely used for the manufacturing plant.Jackson's robot has development prod high speed robots from the first generation 4 axis collaborative robots to the second-generation robot with higher performance.
Advantages
◎Easy to operate -Simple and easy to use.It can be used normally after setting by a simple graphical parameter interface.
◎Easy to debug -According to the actual trajectory, the corresponding parameter can be adjusted. Clear schematic diagram,select the corresponding stacking layout according to the product layout.
◎Wide range of application -There are many types of stacking,including matrix,return type, and custom. The approach method can be formulated according to the different needs. This function can be used for stacking all regular objects.

Main Technical Parameter
| Structure style | Vertical multi-joint robot | |
| Degree of freedom | 6axis | |
| Payload | 50 KG | |
| Max radius of activity | 2449mm | |
| Repeated positioning accuracy | ±0.8mm | |
| Activity range | S axis | ±165° |
| L axis | 2505mm | |
| U axis | 1387mm | |
| R axis | ±135° | |
| B axis | ±130° | |
| T axis | ±360° | |
| Body weight | 550KG | |
| Environmental conditions | Temperature | 0~45° |
| Humidity | 20- 80%RH(No condensation) | |
| Vibration | Below 4.9m/S2 | |
| No flammable and corrosive gas or liquid Do not involve water, oil, powder Do not approach the source of electromagnetic gas |
||
| Battery capacity | 4.2KVA | |
