Application
A large number of thermos bottle manufacturers need thermos cup printers with higher printing speed and higher output. JACKSON three-row six-station cylinder printer can meet this function.
Advantages
◎Three Row Cylinder Printer AC-2513 is upgrade to print three rows of fixture with plus six station two-way printing back and forth at the same time.
◎High production capacity: Up to 240 vacuum bottle per hour
◎Printing design color is also excellent and vivid
◎3D relief effect is strong
◎After cylindrical printing ,vacuum bottle design has wear-resistant, heat resistant water.Even soaked in the cold water , the design color are not fade .
Main Technical Parameter
| Equipment model | AC-2513 Three Row Clyinder Printer |
||
| Nozzle settings | RICOH G5i nozzle head 3-9pcs optional | Working size | Three row 6 stations (2500mm/row) |
| Nozzle accuracy | 7PL/5PL | Printing speed |
240pcs/h |
| Ink color | CMYK+LCLM+W+V | Printing height | 2-100mm(custom-mode250- 350mm) |
| RIP App | RIPrint/ONYX | Print resolution | 600*1 200/1800dpi |
| Curing method |
WATER COOLING (double/four lights) (varnish) LED curing |
Power requirements |
220V/3500W |
| Lifting method | Car lift | Operation system | Windows 7 Ultimate 64-bit |
| Transfer method | Double HIWIN guide+Double screw +Metal grating | Environmental requirement | Temperature 20-28°C Relative humidity40 -60% |
| Machine Weight | 1100kg | Machine size | Width4400* length 2200* height 1700mm |
