Advantage:
1. Eco-friendly European Standard.
2. Capacity: Quality require 8H/cycle
a.Good brands.
b.For 500ML bullet bottle, 1200pcs/tank, about 7000pcs/24h.
c.For top quality for brand name, 8 hour 1cycle; Stand quality, 6 hour 1cycle.
d.Energy saving, 10 temperature ranges PLC control, uniform heating-up & vacuum perfectly.
e.One extra mechanical pump as standby, keep production line without disturbing.
f. Heating evenly: Ribbon heating widely and evenly, average locates in front, back & center.
g.With correct process & operation, success rate can reach to 90-98%.
Notes:
1.Water pump,5kgs air compressor,10CBMS water pool with 1-1.5kgs pressure, flask rack requested.
2.9pcs basket for flask & kettles for free.
Main Technical Parameters
|
Main Technical Parameters |
Leaded vacuum |
Lead-Free vacuum |
|
Model |
JSB-V1800L |
JSB-V1800LF |
|
Function |
Flask & double wall water bottle vacuum suction for insulted thermal |
|
|
technology |
Vacuum, gasp, heat, detect |
|
|
Furnace volume |
1800*1500mm |
|
|
Studio size |
6500*3875*4635mm |
|
|
Max temperature |
580℃ |
650℃ |
|
Temperature uniformity in the furnace |
Less ±5℃ |
|
|
Working vacuum |
≦5×10-3Pa |
|
|
Leakage rate of vacuum chamber |
≦1×10-1pa/min·v; |
|
|
Working heating temperature |
≦540℃ |
≦620℃ |
|
power |
66KW+25KW |
124KW |
|
voltage |
AC 380V/AC 415V |
|
|
Weight |
13000kg |
|
